"Some guitars are built for performance, some for aesthetic. These instruments are the best of both worlds... and perhaps the universe!"
| + SPECS |
| Neck Type: | PIA / 5pc Maple / Walnut neck |
| Top/Back/Body: | Alder body |
| Fretboard: | Rosewood fretboard / PIA Blossom inlay |
| Fret: | Jumbo Stainless Steel frets / Prestige fret edge treatmen |
| Number of Fret: | 24 |
| Bridge: | Edge bridge |
| String space: | 10.8mm |
| Neck Pickup: | DiMarzio® UtoPIA™ (H) neck pickup (Passive/Ceramic) |
| Middle Pickup: | DiMarzio® UtoPIA™ (S) middle pickup (Passive/Alnico) |
| Bridge Pickup: | DiMarzio® UtoPIA™ (H) bridge pickup (Passive/Ceramic) |
| Factory tuning: | 1E,2B,3G,4D,5A,6E |
| Strings: | D'Addario® EXL120 |
| String gauge: | .009/.011/.016/.024/.032/.042 |
| Nut: | Locking nut |
| Hardware Color: | Gold |
| + Neck Dimensions |
|---|
| Scale: | 648mm/25.5" |
| a: Width: | 43mm at NUT |
| b: Width: | 58mm at 24F |
| c: Thickness: | 18mm at 1F |
| d: Thickness: | 20mm at 12F |
| Radius: | 430mmR |
| Guitar Neck Diagram |
| a: Width of the neck at the nut |
| b: Width of the neck at the first fret |
| c: Thickness of the neck at the first fret |
| d: Thickness of the neck at the twelfth fret |
| Radius: Radius of the fingerboard |
SWITCHING SYSTEM
CONTROLS
| + OTHER FEATURES |
|---|
| Recommended Bag: IGB724-BK |
| Gotoh® machine heads |
| High-pass filter on volume control (push/pull) |
| Luminlay side dots |
| Hardshell case included |
| Ultralite Tremolo Arm™ included |
